New Technology Wireless Lora Radar Water Level Meter Liquid Level Meter for Tank Meter for Monitoring Water and Liquid Levelmeter



This is a new technology wireless radar water level meter for monitoring water and liquid levels in tanks, using non-contact measurement. It operates at 76~81GHz, with a standard measurement range of 0-65m (customizable to 66m-120m), ±1mm accuracy, and an 8° beam angle. Working in -40℃~75℃ with IP68 protection, it features POM, aluminum alloy, or stainless steel housing, supports 18-28 VDC power, and outputs via 4-20mA (with Bluetooth) and RS485. Installable via bracket or thread, it suits rivers, embankments, lakes, etc., with a 1-year warranty.



● ±1 MM Error

● 80 GHz FMCW

● 5 GHz Working bandwidth

● Minimum 8° Beam angle

● Support custom custom Measurement Range of 66m-120m





Transmission frequency	76GHz~81GHz
Measuring range	0-65m ,>65m can support customization
Measurement accuracy	±1mm
Beam angle	8°
Type	Non-contact
Power supply range	18-28 VDC
Output	4-20ma(Supports Bluetooth),RS485
Operation temperature	-40℃~75℃
Shell material	POM/aluminum alloy/stainless steel
Antenna type	lens antenna
Recommended cables	0.5mm²
Protection grade	IP68
Installation method	Bracket/Thread(supports various custom connections)
